DC power cord DCC series DCC-12/13/14/18/20

The 90R12 is a mass fusion splicer capable of splicing up to 12 fiber ribbon cables simultaneously. In previous mass fusion splicer models, the v-grooves could become dirty over time due to debris and glass deposits from splicing accumulating in the v-grooves. Which in turn, could lead to fibre offsets and high losses if they were not regularly cleaned which added to the overall process time. The 90R12 comes with a first of its kind, innovative user replaceable V-groove assembly which makes this issue a thing of the past and is supplied as standard equipment with the 90R12 kit. This new V-groove assembly can be quickly and easily fitted in the field, minimizing downtime and maximising productivity. In addition, the new V-groove design enables splicing of both conventional type 12-fiber encapsulated ribbon and SWR (Spider Web Ribbon) whilst also accommodating 250um and 200um pitch fibers. The 90R12 can also splice single fibers if required. also making use of Active Blade Management Technology, which now can connect to two CT50 cleavers simultaneously.

FEATURES: Cleaver tracking and upkeep with wireless communication Improved real-time arc control for fibers with poor cleave angles Loose and tight buffer with same sheath clamp Automated wind protector, sheath clamps and splice operation Graphical User Interface with 5.0" Touchscreen PC software and 90S manual downloaded from splicer Multi-function transit case with integrated workstation Lithium-ion battery with 300 splices/shrinks per charge APPLICATIONS: Distribution fiber repair Long-haul network installation Field termination with splice-on connectors Access network installation Fanout kits, pigtails and splice cassettes OSP cable installation and repair Optical modules – splitters, couplers, MUXs, EDFAs and attenuators

FEATURES: Warm Splice Imaging (WSI) loss estimation technology Improved real-time arc control for fibers with poor cleave angles Bluetooth enabled cleaver management Two camera, active cladding alignment 5" touchscreen monitor Interchangeable sheath clamps and fiber holders Fully ruggedized for shock, moisture and dust resistance Extended-life electrodes, 5,000 splices, exchangeable without tools

The Fujikura specialty fiber splicer FSM-100P series offers a host of innovative technologies to address the rapidly expanding splicing needs for factory, manufacturing, laboratory and R&D applications. These capabilities is revolutionizing the way users splice various types of specialty fibers, LDFs, PMFs and so on.
